mobiler EKG Monitor

Its large, high resolution LCD display gives clear, easy to read results and is suitable for use in hospitals, clinics, health centres, nursing homes, residential homes, offices etc. It gives accurate and reliable readings at your most convenience if it is for private use. It is also cost effective to health Professionals as patients are screened and filtered at this stage before referring them to hospitals.

If you have any questions or concerns in any of the ECG records, you can capture the recording and mention it to your health professionals for advice. Data can be transferred to PC, laptop etc should it need to be shown and analyzed further by health professionals.

• FDA approved
• Easy to read – Large, color LCD display with lit background
• Compact, lightweight and easy to use – can be used by patients
• Provides an accurate diagnosis on par with professionals, clinics and hospitals
• ECG waveform and interpretation of results are displayed clearly on dot-matrix LCD screen.
• Quick 30 second single-channel ECG waveform analysis with/without electrodes
• Presents results with up to 17 different types of ECG waveforms and heart rate display
• Signal amplification (Gain Mode)
• Up to 1200 records for quick measurement or 10-hour data records for continuous measuring can be stored in built-in memory.
• Holds up to 300 x 30 second records with data lock function to prevent accidental removal
• USB port to transfer externally to PC for data management (Software and cable included)
• Powered by 2 x AAA batteries (included) with low voltage indication
• Support 10 hours continuous monitor
• Chest lead & limb lead measure available
• Data records can be reviewed, copied, deleted, and uploaded as well.
• 50 electrode pads included

• Display Mode: Color LCD display
• The number of measuring channel: Single channel ECG signal.
• Resolution:  240*160
• Screen Size (mm): 40*57.6
• Signal Input: Single embedded metal electrodes or external lead wire
• Lead Selections & Measuring Modes: Quick measurement by embedded electordes; Measurement by external electrodes with lead wires(single channel for Lead I、II、or III)
• ECG Bandwidth: 1-40Hz
• Internal Noise Level: ≤30uVp-p
• Heart Rate Range: 30-240bpm
• Heart Rate Accuracy： ±2bpm or ±2%，whichever is greater
• Display Scale: 5mm/mV ±10%
• Input loop current: ≤0.1μA
• Input impedance: ≥5 MΩ
• CMRR：≥60dB
• Wave Form Sweeping Speed: 20mm/s±10%
• Measurement Time: 30 seconds per test
• Dimensions（mm）: 125*70*21.5
• Net Weight (without Batteries): 106g
• Power Supply: 2*AAA batteries
• Voltage: DC 5.0V/1.0A

Package:

• 1x ECG Monitor
• 2x batteries
• 1x manual with picture illustrations
• 1x USB cable
• 1x ECG lead wire
• 50 electrode pads(in 2 bags)
• 1x CD （ECG waveform Viewer）
